950W Redundant Power Supply (3.07"x9.06")

TG14-0950 Series

Universal Input Voltage Range: 90–264VAC.
Built-in Active Power Factor Correction (Active PFC) Function.
Delivers 950W Output with Forced Air Cooling.
Dual Output Design with High Efficiency up to 90%.
High Power Density Design with Compact Dimensions: 9.06" × 3.07" × 1.59".
Operating Ambient Temperature Range: 0°C to +50°C.
Comprehensive Protection Features: Short Circuit Protection (SCP), Over Current Protection (OCP), Over Voltage Protection (OVP), and Over Temperature Protection (OTP).
N+1 Redundancy Design with Active Current Sharing.
Supports Digital Power Management via PMBus.
Reliable Operation at Altitudes up to 5000m.
Compliant with IEC62368-1 Safety Standard.
Ideal for Servers, Data Centers, Networking Equipment, Telecom Systems, and Industrial Automation Applications.

950W Redundant Power Supply_Specification

‌

Model Name		TG14-0950-02/03
Output	Rated Power	950 W
	Output Voltage	12 Vdc	56 Vdc
	Maximum Output Current	16.7 A	13.4 A
	Over Current Limit	17.5~22.5 A	14.0~18.1 A
	Minimum Output Current	0 A	0 A
	Ripple & Noise	≦ 1 %	≦ 1 %
	Hold Up Time	≧ 8 ms @80% Load
Input	Input Voltage	90~264 Vac
	Input Frequency	47~63 Hz
	Power Factor	≧ 0.95 @100% Load, 115Vac/60Hz
	Efficiency	≧ 90%
	Inrush Current	≦ 30 A @115Vac/60Hz, 25°C ; ≦ 60 A @230Vac/50Hz, 25°C
EMC	Surge	4KV (L/N-G), 2KV (L-N)
	EMI	EN55032
	ESD	IEC61000-4-2
Environmental	Operating Temperature	0~+50 °C
	Storage Temperature	-40~+80 °C
	Operating Humidity	20~80 %RH
	Storage Humidity	5~95 %RH
	Operating Altitude	5,000 m
Others	Fan Airflow Direction★	TG14-0950-02: Air Flow Out (AFO) ; TG14-0950-03: Air Flow In (AFI)
	Dimension (W x L x H)	78 x 230 x 40.5 mm (3.07 x 9.06 x 1.59 inch) ; 1U
	Mean Time Between Failures	≧ 100,000 hours @230Vac/50Hz, 25°C
	Certifications	CB, TÜV, UL/cUL
