SPECIFICATION
Model Name TG13-0270-01
Output Rated Power 270W@25°C~230W@50°C
Output Voltage 3.3 Vdc 5 Vsb 5 Vdc 12 Vdc -12 Vdc
Maximum Output Current 10.0 A 2 A 12.0 A 16.0 A 0.3 A
Over Current Limit 18 A - 20 A 20 A -
Minimum Output Current 0.5 A 0 A 1 A 1 A 0 A
Ripple & Noise ≦ 100 mVp-p ≦ 200 mVp-p ≦ 100 mVp-p ≦ 200 mVp-p ≦ 200 mVp-p
Hold Up Time ≧ 17 ms
Input Input Voltage 90~264 Vac
Input Frequency 47~63 Hz
Power Factor ≧ 0.9
Efficiency ≧ 85 % @50% Load, 100~240Vac ; Meet 80Plus Bronze
Inrush Current ≦ 50 A @100Vac, 25°C ; ≦ 120 A @240Vac, 25°C
EMC Surge 2KV (L/N-G), 1KV (L-N)
EMI EN55032, FCC Part 15
ESD IEC61000-4-2
Environmental Operating Temperature 0~+50 °C
Storage Temperature -40~+70 °C
Operating Humidity 5~85 %RH
Storage Humidity 5~95 %RH
Operating Altitude 3,000 m
Others Dimension (W x L x H) 81.5 x 150 x 40.5 mm (3.2 x 5.9 x 1.6 inch) ; 1U
Mean Time Between Failures ≧ 100,000 hours @100Vac/50Hz, 25°C
Certifications CB, UL/cUL
*Specifications are subject to change without notice
