SPECIFICATION
Model Name TG-7601-ES
Output Rated Power 75 W
Output Voltage 24 Vdc
Maximum Output Current 3.125 A
Over Current Limit 8 A @10A/s slew rate
Minimum Output Current 0 A
High Peak Power 9 A
Ripple & Noise ≦ 240 mVp-p
Hold Up Time ≧ 10 ms
Input Input Voltage 90~264 Vac
Input Frequency 47~63 Hz
No-load Power Consumption ≦ 0.15 W
Efficiency ≧ 89 %
Inrush Current ≦ 40 A @115Vac, 25°C ; ≦ 80 A @230Vac, 25°C
EMC Surge 2KV (L/N-G), 1KV (L-N)
EMI EN55032, FCC Part 15
ESD IEC61000-4-2
Environmental Operating Temperature 0~+40 °C
Storage Temperature -40~+70 °C
Operating Humidity 20~85 %RH
Storage Humidity 10~95 %RH
Operating Altitude 5,000 m
Others Dimension (W x L x H) 80 x 165 x 50 mm (3.15 x 6.5 x 1.97 inch)
Mean Time Between Failures ≧ 100,000 hours @25°C
Certifications CB, UL/cUL, FCC, CCC, LPS, PSE, KC
*Specifications are subject to change without notice
